Model :DH2000-Mini
Keyword :Deuterium tungsten lamp, deuterium halogen lamp, absorption spectrum, reflection spectrum, transmission spectrum
400-820-7939
Technical Support：021-50687686
UV/VIS/NIR light source, spectrum range of 200~2500nm, SMA905 standard interface, small size, flue gas detection, water quality analysis, scientific research
◆ The?spectral?range?covers?200-2500nm;
◆ Manual?or?TTL?signal?to?control?the?shutter;
◆ Separate?deuterium?lamp?and?tungsten?lamp?on?and?off;
◆ Compact,?high?stability,?long?life.
Specifications |
|
| Item | Value |
| Wavelength range | 200～410 nm(Deuterium lamp)；350～2500 nm(Tungsten lamp) |
| Output | 3.8W(Deuterium lamp)；1.2W(Tungsten lamp) |
| Stability | 0.25%/h |
| Time to stabilize | 10 min(Deuterium lamp)；10min(Tungsten lamp) |
| Life | Deuterium lamp：2000hrs;Tungsten lamp:6000hrs |
| Delay time | <2.0s(It takes longer when the temperature is low) |
| Trigger control | TTL |
| Connector | SMA 905 |
| Numerical aperture | 0.245@氘燈 |
| Fiber core | 200 – 1000um |
| Power requirement | 600mA @ 12 VDC |
| Input voltage | 12V/2A |
| Dimensions | 190x105x78mm |
